Vector Optics - 30mm Extreme High AR Scope Mount - Picatinny - Black - XASR-3038

One-piece mount for a scope with a 30mm tube, primarily for the AR platform from Vector Optics. Its elongated design allows you to increase the distance between your eye and the scope's eyepiece. Making the body of the mount from milled 6061-T6 aluminum has maintained high rigidity, which is crucial when withstanding the loads generated after firing the weapon.

The versatility, or more specifically, the flexibility of application, allows the assembly to be used with a variety of platforms. This is made possible by a low dead weight of just over 150 grams. In addition, the high mounting profile does not require the user to remove mechanical sighting instruments. The XASR-3038 mount raises the aiming line to a height of 50 mm (1.97").

Attaching the part to the Picatinny rail is done through two hooks, about 5 cm apart. All components of the assembly are bolted together with Torx T15 screws, which have a tightening torque of 2 to 2.4 Nm. Each of the mounting rings is secured by four screws, and each abutment by two.

Features:

• One-piece scope mount that raises the aiming line by 50 mm
• Mounting in Picatinny standard, based on two hooks
• Made by CNC machining from 6061-T6 aluminum alloy
• Extended design allows for increased distance from the eye
• Compatible with 30 mm diameter tubes
• Each of the mounting rings has been secured with four screws
• Structure bolted with Torx T15 screws
